3pcs Low 3.5ohm PCA9306 Dual Bidirectional Voltage-Level Conversion Module Converter

Based on 0 reviews. - Write a review

$17.99

Ex Tax: $17.99

Stock: In Stock
Model: EB0043265
SKU: EB0043265

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Description:

This is a conversion board for the PCA9306 dual bidirectional voltage-level translator. Because different parts sometimes use different voltage levels to communicate, voltage level translators can be the key to making different parts play nice.

The PCA9306 is a dual bidirectional I2C-bus and SMBus voltage-level translator that's operational on the low side from 1.0 V to 3.6 V and on the high side from 1.8 V to 5.5 V. Simply apply your low- and high-side reference voltages to the VREF1 and VREF2 respectively, connect your I/O and drive the Enable pin high to open bidirectional voltage translation without the use of a direction pin!

Features:

2-bit bidirectional translator for SDA and SCL lines in mixed-mode I2C-bus applications.

Standard-mode, Fast-mode, and Fast-mode Plus I2C-bus and SMBus compatible.

Less than 1.5 ns maximum propagation delay to accommodate Standard-mode and Fast-mode I2C-bus devices and multiple masters.

Allows voltage level translation between:

1.0 V Vref (1) and 1.8 V, 2.5 V, 3.3 V or 5 V Vbias

1.2 V Vref (1)and 1.8 V, 2.5 V, 3.3 V or 5 V Vbias

1.8 V Vref (1)and 3.3 V or 5 V Vbias

2.5 V Vref (1) and 5 V Vbias

3.3 V Vref (1) and 5 V Vbias

Provides bidirectional voltage translation with no direction pin

Low 3.5 Ω ON-state connection between input and output ports provides less signal distortion

Usage:

Package includes:

3 x PCA9306 Board
