16S 16 Series SANYUAN 60V 35A Lithium Battery Protection Plate BMS Split Port with Balance for 3.7V Battery

16S 16 Series SANYUAN 60V 35A Lithium Battery Protection Plate BMS Split Port with Balance for 3.7V Battery
16S 16 Series SANYUAN 60V 35A Lithium Battery Protection Plate BMS Split Port with Balance for 3.7V Battery
16S 16 Series SANYUAN 60V 35A Lithium Battery Protection Plate BMS Split Port with Balance for 3.7V Battery
16S 16 Series SANYUAN 60V 35A Lithium Battery Protection Plate BMS Split Port with Balance for 3.7V Battery
16S 16 Series SANYUAN 60V 35A Lithium Battery Protection Plate BMS Split Port with Balance for 3.7V Battery
16S 16 Series SANYUAN 60V 35A Lithium Battery Protection Plate BMS Split Port with Balance for 3.7V Battery
16S 16 Series SANYUAN 60V 35A Lithium Battery Protection Plate BMS Split Port with Balance for 3.7V Battery
$12.99
Ex Tax: $12.99
  • Stock: In Stock
  • Model: EB0045704
  • SKU: EB0045704

Available Options

  • Number of Strings: 16S
    Precise details>>
    Specification:

    Brand:Renhotec
    Model: CF-60V20A
    Product name: 16 series LSANYUAN 60V 35A Lithium Battery Protection Plate
    Discharge current: 35A
    Charging current (Split port): ≤5A
    Main circuit conduction internal resistance: ≤15MR
    Charging voltage: 67.2V
    Short circuit protection: 200US
    Working temperature range: -30℃~+80℃
    Working power consumption: ≤50UA
    Applicable battery:  3.7V
    Overcharge: 4.25±0.025V
    Over discharge: 2.8±0.1V
    Balance: 4.2±0.025V
    Product size: 69 *51.5*10mm

    Package included:

    1 x Lithium Battery Protection Panel
