PVR608 2MP 1080P POE 8CH PVR Camera Kit Surveillance Camera System with Humanoid Detection
- Stock: In Stock
- Model: EB0024549
- Dimensions: 225.00mm x 218.00mm x 43.00mm
- SKU: EB0024549
| Model | ESCAM PVR608 (Support humanoid detection) | |
| App | P6SLite | |
| Camera Parameter | ||
| Camera | Image Sensor | 1/2.5”CMOS |
| Effective Pixels | 1920*1080(2MP) | |
| Lens | 3.6mm | |
| Angle of View | Horizontal: 80°, Vertical: 58° | |
| Day/Night Mode | Auto switchover | |
| Min. Illumination | 0.1Lux/F1.2(Color); 0.01Lux/F1.2(B/W) | |
| IR Distance | 15m(50 ft) | |
| Backlight Compensation | Support | |
| DWDR | Support | |
| Video | Compression | H.265/H.264 |
| Resolution | Main stream:1920*1080(1080P),1280*720(720P) | |
| Sub Stream:800*448(448P),704*576(D1),640*360(360P),352*288(CIF) | ||
| Bit rate | 64 Kbps~ 12Mbps | |
| Frame Rate | 25fps | |
| Audio | Interface | Not support |
| Network | Interface | One 10M/100Mbps RJ45 |
| Network Protocol | HTTP,TCP/IP, RTSP, SMTP, NTP, DHCP, DNS, DDNS, P2P network protocol | |
| Browser Supported | IE browser | |
| OS Supported | PC: Windows; Smart Phone: iOS, Android | |
| Onvif | Support | |
| General | Power Supply | DC12V & PoE (IEEE 802.3at) |
| Power Consumption | <6W | |
| Working Environment | -30℃~+55℃(14°F~131°F), 10%~90% | |
| Ingress Protection | IP66 | |
| Dimensions | 175*67*65mm | |
| Weight | 0.25KG | |
| NVR Parameter | ||
| System | GUI | 16-Bit menu interface |
| Operating System | Embedded linux OS | |
| A/V Input | Video Input | 8 x POE IP Camera |
| Audio Input | Not support | |
| A/V Output | VGA Output | 1024*768,1366*768,1280*1024,1920*1080 (1080P) |
| HDMI Output | 1024*768,1366*768,1280*1024,1920*1080 (1080P) | |
| Audio Output | Not support | |
| Playback Resolution | 1080P/720P | |
| Synchronous Playback | 1 Channel | |
| HDD | Interface Type | 1 SATA interface |
| Maximum Capacity | 6TB (not include HDD) | |
| External Interface | USB Connector | 2 x USB 2.0 |
| Network Interface | One 10M/100M ethernet RJ45 port, four network POE ports for IP cameras | |
| Network | Network Protocol | HTTP,TCP/IP, SMTP, NTP, DHCP, DNS, DDNS, P2P network protocol |
| Mobile Device | iOS, Android Smartphones | |
| Remote Software | App, PC Client (Windows) | |
| Onvif | Support | |
| General | Power Supply | Input 110~260V, 52V 1.8A |
| Consumption | <20W without POE Cameras | |
| Working Environment | -10°C~+45°C (14°F~113°F),10%~90% | |
| Dimension | 255*218*43mm | |
| Weight | 0.75kg | |
| Package information | Dimension | 345*275*285mm |
| Weight | 6.45kg | |
| Packing List | 8CH POE NVR(not include HDD) x 1, POE IP camera x 8, NVR power adapter x 1, Guide x 1,15m network cable x 8, USB mouse x 1, Screws package x 8, Waterproof hat x 8 | |
